Cryogel Z Flexible Aerogel Blanket Insulation

Cryogel Z Flexible Aerogel Blanket Insulation

Cryogel Z flexible aerogel blanket insulation is engineered to deliver maximum thermal protection with minimal weight and thickness. Cryogel Z is composed of a flexible aerogel blanket laminated to a vapor retarder. This powerful combination makes Cryogel Z unmatched in sub-ambient, cold cycling, and cryogenic applications.

Cryogel Z’s extremely low thermal conductivity minimizes heat gain and liquid boil-off. Cryogel Z remains flexible, even at cryogenic temperatures, eliminating the need for complex and costly contraction joints, thereby resulting in simple and faster installation. It is designed for long term performance while also withstanding incidental mechanical abuse, leading to continued protection through the life of the asset. Cryogel Z is ideal for faster and safer installations for both maintenance work and new builds.

In addition to being the first choice in cold conservation, Cryogel Z based systems offer acoustic attenuation and protections against cryogenic spill, pool fire, and jet fire. The combination of these safeguards make Cryogel Z ideal for onshore, offshore and marine applications.


Get More Info


Category: Tags: ,

Product Description


• Extremely low thermal conductivity (k-value) enables thinner designs for improved space efficiency
• Integrated vapor retarder provides redundant protection in an easy-to-install package
• Eliminates the need for contraction joints reducing cost and complexity
• Durable and flexible even at cryogenic temperatures
• Robust performance during construction, transport and operations makes it suitable for pre-insulation and modular builds
• Increased labor productivity and faster installation rates
• Proven in global LNG liquefaction and regasification facilities
• Thermal, acoustic, jet-fire, pool fire, and cryogenic spill protection in a single system

Physical Properties of Cryogel  Z

Thickness*:  0.20 in (5 mm) / 0.40 in (10 mm)
Roll Size*:  Approx. 1250 sqft; 58 in (1450mm) wide / Approx. 700 sqft; 58 in (1450mm) wide
Max. Use Temp.:  257°F (125°C)
Color:  White
Density*:  10.0 lb/ft³ (0.16 g/cc)
Hydrophobic:  Yes
*Nominal Values

Performance of Systems Incorporating Cryogel Z

The performance of Cryogel Z in cold acoustic service and passive fire protection systems has been evaluated according to the test methods described below. Performance levels achieved in these systems are configuration dependent. Contact Aspen Aerogels technical service for configuration and other details.
• UL 1709 – Rapid Rise Fire Test: Up to 150 min of protection
• OTI-95-634 – Jet Fire Protection: Up to 120 min of protection
• ISO 15665 – Acoustic Insulation for Pipes, Valves, and Flanges: Configurations meeting Class A2, B2, C2, and Shell D2 possible
• IMO Part 2 and 5: Effective July 2019, use only Cryogel Z (IMO grade) for applications requiring compliance with IMO Part 2 and 5. Standard grade Cryogel Z is only appropriate for applications that do not require compliance with IMO Part 2 and 5. Contact Aspen technical service for additional information.

Specification Compliance and Peformance

ASTM C165, ASTM C356, ASTM C795, ASTM C1101/1101M, ASTM C1104/1104M, ASTM C1338, ASTM C1617, ASTM C1763, ASTM E84, ASTM E96
