Design Polymerics DP 502 100% RTV Silicone

Design Polymerics DP 502 100% RTV Silicone

A high-performance HVAC, industrial, commercial, and residential construction grade 100% Acetoxy RTV Silicone adhesive/sealant with excellent resistance to aging, weathering, and UV degradation. DP 502 will provide long term performance on both interior and exterior applications without sagging or slumping.

Get More Info

Product Description

Recomended Uses
DP 502 is recommended on a variety of HVAC substrates including galvanized steel, stainless steel, aluminum, wood, fiberglass, PVC, PVS, and painted substrates.
DP 502 is an excellent sealant and adhesive for many commercial, industrial, and construction applications where a long-term, permanently flexible seal/bond is required.
DP 502 will not sag or slump and can be applied to both vertical and overhead substrates.

Features and Benefits
• LEED V4 Qualified
• Non-Slump, Non-Sag
• Mold and Mildew Resistant
• Low VOC
• Weather and UV Resistant
• Flexible, will not shrink or crack
• Indoor and Outdoor Usage

Meets or Exceeds
• ASTM C920 Type S, Grade NS, Class 25
• ASTM G26
• TT-S 001543A, TT-S 00230C Type II
• FDA Regulation No. 21 CFR177.2600
• NSF Standard 51
• UL Recognized
• MIL-46106 TYPE 1

Technical Data
Colors: Clear, White, Black, Aluminum Gray
Base: 100% RTV Silicone
Viscosity: Approx. 550,000 to 600,000 cps
Skinning Time: Approx. 10 minutes at 70°F, 50% RH
Shore A Hardness: 25
Tensile Strength: 264 psi
Elongation: 500%
Gun Grade: Pass, Non-Slump
QUV Testing (ASTM G26): Pass 10,000 hours
Application Temperature: -35°F to 150°F
Storage: Store in original unopened container below
90°F. High humidity and high heat can reduce shelf life.
Service Temperature: -50°F to 400°F. Intermittent
Temperatures up to 500°F.
Flammability: Non-flammable wet or dry
Flash Point: No flash to boiling
Shelf Life: One Year (unopened container)
Cure Time: 24 hours at 1/8” bead, depending on temperature, humidity, and application
Clean Up: Uncured DP 502 can be cleaned with mineral spirits or denatured alcohol
Painting: DP 502 is not paintable
Packaging: 10 fl. oz. tubes
VOC: 23 g/l
