3M Fire Barrier Plastic Pipe Device (PPD)

3M Fire Barrier Plastic Pipe Device is a one-piece metallic collar assembly encasing 3M Fire Barrier FS-195+ Intumescent Wrap Strip material. Manufactured with 3M’s firestop technology, 3M Fire Barrier Plastic Pipe Device has been designed to firestop non-metallic penetrations in fire rated assemblies, helping prevent the passage of smoke and flames in the event of a fire.  3M Fire Barrier Plastic Pipe Device is used for new and retrofit installations and will accommodate nominal 6 in. (152 mm) schedule 40 waste and vented nonmetallic penetrants.

Categories: , Tag:

Product Description

Applications

3M Fire Barrier Plastic Pipe Device provides a rapid and simple method of sealing wall, floor and floor/ceiling assembly non-metallic penetrations where fire
resistance is needed.

3M™ Fire Barrier Plastic Pipe Device can be used to seal ccPVC, PVC, CPVC, FRPP, PVDF, ccABS and ABS pipes penetrating up to 3-hour fire rated assemblies.
Assemblies may be constructed of gypsum wallboard, solid concrete, concrete blocks and even hollow core concrete floors. See a third-party Fire Resistance
Directory for up to date through penetration systems and designs.

Features

  • Intumescent – Expands when exposed to heat sealing voids created by
    combustible items
  • One piece – making installation rapid and simple
  • Factory made, assuring consistent build quality
  • Smoke seal – retards spread of toxic by-products of combustion
  • Superior aging properties
